Production and application of flexible PI heaters

Flexible heaters are a product family that generally describes thin, flexible heating elements that connect the heater to objects to provide frost protection and maintain temperature. The temperature of the polyimide flexible heater can be controlled from -40°C to +250°C. These flexible heaters are mainly produced by etching technology and lamination of polyimide heaters. These types of heaters are typically 0.13-0.4mm thick and are used in many industries for fixed pipes, food heating equipment, and many applications. Since silicone rubber has excellent water resistance, it can be used for many outdoor purposes.

PI heater multiple heating zones

PI heating sheet is a product that is sandwiched between two layers of PI insulation film and a layer of heating conductor. It generates heat after being powered on. The required temperature can be adjusted according to the resistance value of the heating conductor. When the flexible PI heater is designed for a specific power, a resistive metal with resistivity characteristics is formed, and the basic principle of achieving the heater is uniform heating. Heating with a specific power to meet a customer-defined total resistance and relating the power output to the applied voltage.

The main difference between wire-wound and etched foil technology is that the etched foil production process is primarily made of materials from specific metal alloys rather than other wires. When designing polyimide heaters, we mainly conduct research and adjustments based on the design plans provided by customers, and conduct mass production based on actual applications.

Advantages of PI heaters

The width of the PI heater can be adjusted according to the needs of the product to achieve equivalent resistance and realize the normal heating process of heat. It is insulated by electric welding and then sealed by adding a layer of silicone. There will also be some heater designs with special patterns. This precise patterning ability can be converted into uniform heat distribution, which also puts designers to the test of accuracy.

PI heaters are thin, easy to bend and have fast heat transfer speed. The PI heater is thin and light, so it can be applied to some products that have space requirements, and it can also adapt to bending in different shapes. The heat transfer is uniform and fast. By accurately arranging the line spacing, the heater can heat evenly, and the product can be heated up quickly through electric heating to reach a certain temperature. The material of the PI heater is also corrosion-resistant. After testing in high temperature and cold environments, the heater can be used normally without affecting its heating effect.

PI heater application introduction

The flexible PI heater can closely fit the surface of the product and transfer heat well. In addition, flexible heaters have their own design and construction based on the specific needs of the application, which also allows the heater to have a personalized design. Therefore, the application range is also wider. At the same time, assembly is faster. There is PET glue on the back of the flexible PI heater to better install it on the product. At the same time, the use of the product will not be affected by the high temperature during use, and it is not easy to break away.

Flexible PI heaters are used in various products that require heating. Based on unique product design and circuit layout, the heater is more suitable for each customer's product. Danyu Technology has more than ten years of experience in heater research and production, and has multiple patents and product quality certifications. If you have any needs for heaters or heating products, you are welcome to contact us for consultation.
